Fiber patch cords and pigtails
OS2 single-mode and OM3 or OM4 multimode, simplex or duplex, with LC or SC connectors, in the length you need.
Fiber and CAT6 patch cords, made to order in the length you need
From Noida, Rudra Optical Technologies supplies fiber and CAT6 patch cords made to order, plus pigtails, adapters, PLC splitters, LIUs and CPRI jumpers.
Patch cord builder
Fiber or CAT6. Each choice updates the drawing and the order line. Send the line on WhatsApp or add it to the quote form, and we will price that exact cord.
Products
Ask for a price on any item, or on anything that isn’t listed.
CAT6 patch cords
Category 6 cords with RJ45 plugs, for switches, patch panels and desks.
FTTH passives
PLC splitters in box and cassette form, OTBs and junction boxes.
To quote: split ratio, connector, pigtail length, and box, LGX cassette or steel tube.
Connectors and adapters
SC adapters, and field-fit SC/APC connectors that terminate drop cable without a fusion splicer.
To quote: connector, polish, simplex or duplex, and the drop cable size for fast connectors.
Fiber management
19-inch rack panels, supplied loaded with adapters and pigtails.
To quote: port count, adapter type, single-mode or multimode, and whether it comes loaded.
CPRI cables
Fiber jumpers between the baseband unit and the radio.
To quote: the connector at each end, the length and the jacket.
Tested before dispatch
| Parameter | Single-modeSM UPC | Single-modeSM APC | MultimodeMM PC |
|---|---|---|---|
| Insertion loss | ≤ 0.30 dB | ||
| Return loss | ≥ 50 dB | ≥ 60 dB | ≥ 30 dB |
| End-face | 0°, domed | 8°, angled | 0°, domed |
| Fiber | OS2, ITU-T G.652.D or G.657.A1/A2 | OM3 or OM4, 50/125 µm | |
- A
- Core, ø 0–25 µm
- B
- Cladding, ø 25–115 µm
- C
- Adhesive, ø 115–135 µm
- D
- Contact, ø 135–250 µm
Inspection zones for single-mode connectors, as set out in IEC 61300-3-35. The outer circle is the 400 µm field of view.
Request a quote
List the items, one per line. Send drawings or photos on WhatsApp or to rudraopti@gmail.com.
